Host size

680x550x1400mm (Length, width and height)

Host + taping size

680x1070x1400mm (Length, width and height)

Support IC packaging

QFN,SOP,SSOP,TSSOP,SON,QF...

Pick and place device

Vacuum nozzle*2

Burning station

4

Monitor

7"LCD

Accuracy of pick and place

士0.03mm

Way to control

Embedded control board

Burning method

 Down-press burning seat

Feeding device

Standard 12-16mm, optional 8-32mm feeder

Discharge device

Adjustable automatic hot pressing film sealing device

Input voltage

AC 220/50ZHz

Power

0.25kw

Gas source

0.4-0.6MPA

Total weight

1 40KG
